| Accuracy: ±2°C temperature corrected |
| Repeatability: 0.8°C |
| Response time: 95% of step change in 3 min. |
| Sample flow: >1 LPM |
| Temperature Sensor | Range: -40°C to +70°C |
| Accuracy: ±2°C |
| Pressure Sensor | 2 to 150 PSIA ±1%, 316L stainless steel wetted parts; higher pressures can be ordered optionally |
| Ergonomics | Comfortable to hold in hand, contoured body design, lightweight 1.75 Lbs |
| Hook and magnet for easy temporary field securing / mounting |
| Easy to read graphic LCD display with user controlled backlight brightness (LCD is readable without the backlight) |
| Snap dome tactile membrane switches with dynamically assigned legends |
| Audible feedback upon button press as well as for warnings and alarms |
| Auto scaling graph / histogram on moisture measurement display for stability verification |
| Easy to use with verbose built-in context sensitive Help screens |
| Battery Saver, with user selectable Auto-power-down times, can also be disabled |
| Built-in pressure measurement and pressure corrected moisture readings, simultaneously displayed with the uncorrected reading for |
| greater ease of understanding |
| Verbose Status bar with indications, warnings and audible errors |
| User selectable locking with or without a password. |
| Built-in battery backed clock calendar |
| Electrical | External AC Universal Power adapter (100-240VAC 50-60Hz) with USB connector |
| Rechargeable Li-Ion battery, recharges through the USB connector from the PC or from the supplied universal power adapter |
| Sampling system and sensor are isolated from electrical interface and supply grounds |
| Measurement resolution of moisture sensor: 1pF resulting in less than 0.01°C |
| External power and I/O: USB mini B female connector – IP67 / IP68 with Sealing Cap |
| Mechanical | 1/8″ Swagelok® Inlet and Outlet fitting adapters for the SAE/MS 5/16-24 ports. |
| Inlet adapter has a built-in flow control orifice, eliminating pressure regulators while maintaining sufficient but not excessive flows. |
| All 316 Stainless Steel and PTFE wetted parts, small surface area stainless steel sampling chamber for fast response time. |
| Integral Sensor retraction into desiccant storage chamber for fast response-time when measuring low moisture |
| Enclosure |
| Impact resistant (>7 Nm to EN 50014) Polyamide 12, |
| IP65/EN 60529 ATEX hazardous area use (Ex II 2 G) approved (PTB 02 ATEX 1076U), |
| Flammability: UL 94 HB |
| Abrasion resistant Polycarbonate display lens |
| Dimensions- L: 7.36″ (187mm) W: 4.17″ (106mm) H: 1.97″ (50mm) |
| Weight Total: 1.75 Lbs (0.8 Kg) |
| Pressure: 150 PSIA (10.3 Bar) — Available with High Pressure Option 500 PSIA (34.5 Bar) |
| Temperature Range | PPMa Analyzer: -20°C to +60°C |
| Electronics: -40°C to +85°C |
| Moisture Sensor: -20°C to +60°C |
| Pressure Sensor: -20°C to +85°C |
| LCD operating: -20°C to +70°C storage: -30°C to +80°C |
| Enclosure: -40°C to +60°C |
| Miscellaneous Features | NIST traceable calibrations |
| Units of measure: °C & °F dewpoint, ppmV, ppmW, µB H2O vapor pressure, grams of H2O / m3, |
| Lbs H2O /106 standard cubic feet in Natural Gas. (All units auto-scaled) |
| Digital & Analog I/O: USB, 4/20mA with HART® |
| Data logging – single point, multipoint, time stamping, each sample records: dewpoint, temperature and pressure, ( memory > 4,000 samples) |
| Virtual Analyzer PC software for training and evaluation, |
| allows the user to experience the exact interface on their own PC with voice explanations |
